Industrial, Industrial PC, Industrial PCs

AEX-2411

Fully IP66 ATEX compliant industrial PC housed in a compact, 316 grade stainless-steel enclosure. Powered by the 6th gen Intel Core i5-6300U perfect for the more demanding applications

Quick Spec

Processor	Intel Core i5 6300U
RAM	4GB – 16GB
IP Rating	Fully IP66
OS Support	Windows 10 Pro/IoT, Linux, Ubuntu
Mounting Type	Flange (wall)/VESA

Datasheet

AEx-2411_V1.3.pdf

Request a Quote Back to Product

Need Help? Contact Us

01462 374102
[email protected]

Intel 6th Gen. Core i5 6300U CPU
SUS 316 Stainless Steel
Total IP66 Grade with M12 Waterproof Connector
Variety of IO applications
WLAN for Option
Wide range DC 9~36V Power Input
Support Panel Mount & VESA Mount
Fanless Design
ATEX Zone2, IECEx and C1D2 Certified

Specification

Processor	Intel Celeron N3350 onboard
Memory	1 x DDR3L SO-DIMM slot, up to 8GB
Graphics	Intel HD Graphics 500

I/O

USB	1 x USB 2.0 Type A 2 x USB 3.1 Gen.1 Type A
LAN	2 x GbE RJ45 (Intel i210/211)

Storage

1 x mSATA (SATA3) slot
1 x Micro SD Card slot

Display

Video	1 x DP 1.2 port
USB3 Type-C	1 x USB Type-C ALT Mode

Expansion

1 x Full-size Mini-PCIe with Micro-SIM slot and 1 x SMA connector for Wi-Fi/BT/LTE options via TB-591
2 x RS-232/422/485 DB9 (COM1/2) via TB-591

Power

Power Button	1 x power button with LED light
Input Voltage	DC 9~36V

Mechanical

Housing	Aluminum Alloy heat sink and plastic bezel
Colour	TANIUM GRAY heat sink and black housing
Mounting	DIN rail and Wall Mount Kit
Dimension	140 x 120 x 42 mm
Net Weight	1.5kg

Environmental

Operating Temperature	0~50°C/ -20~60°C option
Certificate	CE/FCC Class A
Operating System Support	Windows 10 Pro/IoT, Linux, Ubuntu

AEx-2411_V1.3.pdf
