- Fanless Design
- Intel GM45 Socket P Platform
- Total IP65
- LED Backlight
- 1~32V DC Wide Range Power Input
Archive Panel Pcs
APC-3991A_DS-16.pdf
APC-3991AT
Archive product
> 5 year warranty as standard on all products
Quick Spec
| Display Size | 10.1" |
|---|---|
| Mounting Type | VESA |
| IP Rating | Fully IP65 |
| Ambient Temperature | 0°c/50°c |
| Manufacturer | Aplex Technology |
| Vertical Market | Food/Beverage |
Datasheet
APC-3991A_DS-16.pdf
Request a Quote
Discontinued
System
| CPU | Intel Socket P processor support up to Intel P8400 2.26GHz without fan |
| Memory | 1 x 204 Pin 800MHz DDR3 SODIMM slot, up to 4GB |
| System Chipset | Intel GM45 + ICH9M |
| External I/O Port |
|
| Storage |
|
| Expansion Slots | None |
| Power Input | 11~32V DC |
| Touch Screen | Resistive Touch Screen (option) |
| Light Transmission | 80% |
| OS Support | Windows XP Professional, XP Embedded, Windows 7 Pro for Embedded, Windows Embedded Standard 7 |
LCD
| Display Type | 19” Color TFT |
| Max. Resolution | 1280×1024 |
| Max. Color | 16.2M |
| Luminance (cd/m2) | 350 |
| View Angle | 170/160 |
| Backlight Lifetime | 50,000 hrs |
Mechanical
| Construction | Stainless steel |
| Mounting | VESA 100×100 Mount |
| Ratings | IP 65 |
| Dimension | 470×388.6×71.2 |
Environmental
| Operating Temperature | -10~50˚C |
| Storage Temperature | -20~60˚C |
| Storage Humidity | 10 to 90%@ 40˚C, non-condensing |
| Certificate | CE/FCC Class A |
