OTTER-19

These 19″ lightweight rack mounted displays are available in both resistive and PCAP touch. Ideal for industrial enviroments where 19″ racks are required

Categories: Front IP rated Industrial Displays, Industrial, Industrial Display

Quick Spec

Display Size	19"
IP Rating	Front IP65
Touchscreen	Projected Capacitive, Resistive
Mounting Type	Rack Mount/VESA

Request a Quote Back to Product

Need Help? Contact Us

01462 374102
[email protected]

19” Industrial Compact Size Industrial Display
Standard 19″ Rackmount
Flat Front Panel Touch Screen and Fanless Design
DC 12v Power Input
IP65 Compliant Front Panel

I/O Port

VGA	1 x VGA
DVI	1 x DVI-D
Power	1 x 12v DC (9~36V power input optional)
Others	1 x USB type B for touch control Optional I/O: 1 x RS-232 DB-9 for touch control

Display – based on standard display, high brightness option see datasheet

Display Type	19″ TFT-LCD
Max. Resolution	1280 x 1024

Touch Screen

Type	Projected Capacitive / Resistive
Interface	USB default (Resistive/Projected Capacitive Touch) RS-232 Option (Resistive Touch)

Power

Power Input

DC 9V

Mechanical

Construction	Aluminium Magnesium Alloy
Mounting	19″ Rack Mount (6U Height), VESA Mount 100 x 100
IP Rating	IP65 Compliant Front Bezel
Net Weight	5.4kg

Environmental

Operating Temperature	-20~70°C
Certificate	CE/FCC Class A
